Laboratory Power Supply - PKT 1535
laboratory power supply / 1 ... 32 V DC / max current output. 20 A
3-position green LED display / coarse and fine adjustment

The PKT-1535 laboratory power supply allows the level of current and voltage to be adjusted through two separate rotary switches. The adjustment range of the laboratory power supply is between 1 ... 32 V DC or 0 ... 5 A. Due to the commutated output, located on the back of the laboratory power supply, you can adjust up to 20 A. The large 7-segment display of the laboratory power supply allows the user to precisely adjust the output parameters with an accuracy of 100 mA. This is achieved by the coarse and fine adjustment. Thanks to its simple operation, the laboratory power supply can be used in the training area. The current limit setting can be performed in an open circuit. This way,  you no longer need pre-wire with, for example, an additional strength. The smart fan control built into the lab power supply regulates the cooling to the output parameters and temperature, providing long life to this equipment. As the laboratory power supply model is supplied with a safety pin, it can be connected in parallel or series with other PKT-15xx power suply models. This feature provides the user a high degree of flexibility for applications in laboratory, workshop and industry. Here is an overview of different models of a  laboratory power supply and other range of products.

 PKT-1535  laboratory power supply

- Suitable for RF
- 3 pairs of recoverable voltage and current
  values
-  5 A max. setting
- Switchable to 20 A

- Voltage range up to 32 V
- Fine and coarse adjustment
- Lightweight
- Cooling activated by fan

 2 x 3 15 mm digits and 7 colour segments

green

Output current (front)

Delivery  Contents
1 x PKT-1535 power supply, 1 x power cable, 1 x user's manual.
