Infrared Camera PCE-TC 28

Infrared Camera PCE-TC 28
Infrared camera for non-contact measurements / emissivity adjustable /
integrated colour camera / automatic shutdown-function / alarm function /
MIN- and MAX-function / storage facility to save images on MicroSD-card

The infrared camera is designed to perform non-contact measurements of temperatures. In order to make proper measurements this infrared camera offers the chance to adjust the emissivity. The infrared camera possesses the possibility to display infrared images, real images and mixed images. This ensures better visualisation for the operator. Especially the real and mixed images make it a lot easier to target exactly the measurement area that needs to be measured. By having these functions the infrared offers a wide operational framework which can be applied in multiple fields of operation. This includes the manufacturing sites as well as the fields of machinery surveillance and also in certain activies in hobby and free time.

The infrared camera possesses a slot in which a MicroSD-card can be inserted. Depending on the sort of MicroSD-card different quantities of images can be saved. In general we can state that the infrared camera is able to save around 6000 images per gigabyte.

If there are any questions about this infrared camera, please call: UK customers +44(0) 23 809 870 30 / US customers +1-410-387-7703. Our technicians and engineers will gladly give you advice on this professional infrared camera and all other products in the field of measuring instruments, regulation and control, laboratory equipment and scales.

- integrated colour camera
- adjustable emissivity
- quick measurement rate
- MIN- and MAX-function

- backlit TFT colour display
- lens protection
- automatic shutdown-function
- exchangeable Lithium-Ion battery

Technical specifications of the infrared camera

Temperature

Measurement range

-20 ... +300 °C

Resolution (at 25 °C)

±2 %, ±2 °C

Emissivity correction on-screen

yes

Setting the background temperature

yes

Image performance

Image capture frequency

9 Hz

Detector type

Uncooled pyroelectric ceramic

Thermal sensitivity (NETD)

≤150 mK

Infrared spectral band

6.5 ... 14 µm

Visual camera

48608 pixels

Field of view (FOV)

38 x 38 °

Focus mechanism

Fixed focus

Image presentation

Colour palettes

Hot metal
Ironbow
Rainbow
Rainbow high contrast
Grayscale (white hot)
Grayscale (black hot)

Level and span

automatic

Blending information

Parallax correction of visual and IR blending

0.5 m, 1.0 m, 2.0 m, 3.0 m

View options

Blending of the infrared image and visual image in steps of 25 % (from full infrared to full visual)

Hot spot and cold spot tracking

yes

Image capture and data storage

Image capture

Possible to review the image before saving it

Storage medium

MicroSD-card

File format

.bmp

Memory review

Possibility to scroll through the saved images and review them on-screen

Operating temperature

0 ... +50 °C

Storage temperature

-20 ... +60 °C

Relative humidity

10 ... 90 %, non-condensing

Display

2.2 " in diagonal 320 x 240 TFT LCD

Emissivity values

Substance	Thermal emissivity	Substance	Thermal emissivity
Asphalt	0.90 ... 0.98	Cloth (black)	0.98
Concrete	0.94	Human skin	0.98
Cement	0.96	Lather	0.75 ... 0.80
Sand	0.90	Charcoal (powder)	0.96
Earth	0.92 ... 0.96	Lacquer	0.80 ... 0.95
Water	0.92 ... 0.96	Lacquer (matt)	0.97
Ice	0.96 ... 0.98	Rubber (black)	0.94
Snow	0.83	Plastic	0.85 ... 0.95
Glass	0.90 ... 0.95	Timber	0.90
Ceramic	0.90 ... 0.94	Paper	0.70 ... 0.94
Marble	0.94	Chromium oxides	0.81
Plaster	0.80 ... 0.90	Copper oxides	0.78
Mortar	0.89 ... 0.91	Iron oxides	0.78 ... 0.82
Brick	0.93 ... 0.96	Textiles	0.90

Further product- and application images of the infrared camera

All keys of the infrared camera can be reached with one hand and can be operated during measurements.

Different display variants and colour palettes if the infrared camera make the operation easy and comfortable.

The infrared camera is able to display infrared-, real- and mixed images.

Above the trigger, you have the opportunity to read out the infrared camera via the USB-port.

Inside the battery compartment, you can insert the MicroSD-card into the infrared camera.

The scope of delivery also includes a mini-tripod on which the infrared camera can be installed.

At the bottom of the infrared camera there is a thread where the tripod can be mounted.

The trigger of the infrared camera is designed to make a single-hand operation possible.

Scope of delivery of the infrared camera PCE-TC 28

1 x infrared thermometer PCE-TC 28
1 x lithium Ion battery
1 x USB data cable,
1 x mini-tripod
1 x mains adaptor
1 x carrying case
1 x user manual
