Closing Force Meter FM100BT
Closing force device with blueeoth connection / measurement range 0 ... 2000 N / software / standards EN 12445/12453, EN 60335-2, DIN V 18650, ASR A1.7 etc. / robust design /
single button operation / accuracy ±3 % or 3 N / with ISO or DAkkS calibration certificate

The closing force meter has a measurement range of 0 … 2000 N and an accuracy of ±3 N or 3 %. The closing force meter is an electronic pinch force measuring system for power driven doors and gates. Typical applications for the closing force meter include final inspection of new installations and periodic conformance testing of existing equipment. Our closing force meter supports during the measurement the standards EN 12445/12453, EN 60335-2, DIN V 18650, ASR A1.7 and many more.

To make some measurements, it is necessary to connect the closing force meter to an external device via Bluetooth, for example to a mobile phone. If the closing force meter is connected to an external device via Bluetooth, it is possible to make some settings. After a measurement with the closing force meter, it is possible to export the measurement values. It is also possible to generate a report of the values from the closing force meter.

With the closing force meter, it is possible to create a database with all measurements at the external device. For a faster measurement it is possible to save a bar code or a QR code to every test object. The software that comes with the closing force meter has an integrated database, too. The closing force meter comes with an ISO calibration certificate. As an option, it is possible to get the closing force meter with a DAkkS certification.

If there are any questions about the closing force meter FM100BT have a look at the technical specification below or call: UK customers +44 (0) 161 464902 0 / US customers +1-410-387-7703. Our technicians and engineers will gladly advise you regarding all closing force meters and all other products in terms of regulation and control or scales and balances by PCE Instruments.

- measurements are saved on a mobile device
- for power driven doors and gates
- analysis software with database
- easy to use thanks to the single button operation

- measurement range 0 ... 2000 N
- Bluetooth connetion
- supporting EN, DIN and ASR standards
- with ISO or DAkkS certificate

Technical specification

Measurement Range:

0 ... 2000 N

Accuracy

±3 N or 3 %

Stiffness:

500 N/mm

Gap width:

50 mm

Diameter:

80 mm

Measurement technique:

strain gauge bridge

Connection

Bluetooth, Micro-USB

Operating temperature range

-10 to +40 °C / 14 to 104 °F

Storage temperature range

-40 to +50 °C / -40 to 122 °F

Humidity

max. 90% RH, non-condensing

Wireless range

up to 10 m

Size

210 x 80 x 50 mm

Weight

2.1 kg

Delivery content

1 x closing force meter FM100BT, 1 x transportation case, 1 x Android app, 1 x USB cable,
1 x user manual, 1 x calibration certificate
